Apollo Walkable Pro

Load-Rated LED Light Fixture for Walkable Cleanroom Ceiling

Systems The CleanSpace Apollo system is a walkable cleanroom lighting fixture designed for installation within 2” CleanSpace ceiling systems. It provides high-performance illumination while maintaining a sealed, cleanroom-compatible ceiling envelope with full serviceability from above.  Engineered for durability and access, the fixture is rated for 800 lbs static load without damage and incorporates multiple gasketed sealing points to prevent dust, liquid, and vapor ingress.

Engineered for Walkable Cleanroom Ceiling Integration

The Apollo system is designed to integrate directly into walkable ceiling systems while maintaining structural performance and cleanroom integrity. Key features include:

• Rated for 800 lbs static load for walkable ceiling applications
• Installed within 2” ceiling panel systems
• Serviceable from above ceiling space
• Overlapping gasketed frame sealing system
• Designed for high-frequency cleaning environments

Construction and Materials

• The fixture is constructed from heavy-duty materials to support structural loads and long-term cleanroom performance.
• 16 gauge cold rolled steel housing
• Precision formed and welded construction
• TIG welded access door and frame corners
• Reinforced structural brackets for load support
• Neoprene gasket sealing at all interfaces This construction provides durability, structural integrity, and consistent sealing performance.

Performance and Operation

• The Apollo system is designed to deliver consistent lighting performance while maintaining cleanroom compatibility.
• High efficiency LED modules with regulated output
• Standard 4000K color temperature
• 80 CRI with consistent color performance (3 SDCM)
• L70 lifetime greater than 60,000 hours
• Field-replaceable LED modules The system maintains performance under continuous operation and cleanroom conditions.

System Integration

• The Apollo fixture is designed for seamless integration into CleanSpace ceiling systems.
• Installed in pre-cut ceiling panel openings
• 1/2” trade size conduit entry
• Compatible with walkable ceiling panel systems
• Integrated access for maintenance from above The fixture aligns with ceiling systems to maintain a flush and continuous surface.

Jointing and Sealing

• The Apollo system utilizes multiple gasketed interfaces to maintain a sealed cleanroom envelope.
• Gasketed door frame to ceiling interface
• Gasketed lens sealing system
• Gasketed top cover assembly This ensures resistance to dust, vapor, and liquid penetration.

Compliance and Performance

• The Apollo system is designed and certified for use in regulated cleanroom environments.
• ETL certified for wet locations
• IP65 rated for dust-tight and water-resistant performance
• ISO Class 3–8 cleanroom compatible
• NSF2 rated (non-food and splash zone)
• Optional Class I, Div 2 hazardous location certification

Applications

The Apollo system is ideal for:

• Walkable cleanroom ceiling systems
• Pharmaceutical cleanrooms
• cGMP manufacturing environments
• ISO-classified cleanrooms
• Controlled environments requiring sealed lighting systems
